High-Energy Transmission X-Ray

Transmission X-ray Technology

Traditional transmission X-ray images like medical X-rays result when X-rays pass through an object to a detector located on the far side of the object. Objects with greater density block or absorb more X-rays than objects with lesser density. These dense objects produce the characteristic “shadowgram” images similar to medical X-rays. Transmission images are generally high-resolution and result from the X-ray beam being absorbed by objects of varying densities and material composition.

Dual-Energy Technolgy

Transmission X-rays provide high-energy with high-performance for greater penetration and detection—even in dense cargo. In addition, Z Backscatter® technology can complement transmission X-rays by providing context and clarity to expedite inspections and further visualize the shape and form of cargo contents for manifest verification and contraband detection.

Transmission technology can reveal fine details with superb resolution and can offer some level of material discrimination with dual-energy. However, the more objects or clutter in the path of the beam, the less object and material differentiation is achieved. Because of this, many of our products offer a combination of Z Backscatter and transmission technology to give inspectors richly detailed information about the contents of a vehicle or container. Z Backscatter photo-like images also complement transmission X-rays by providing context and clarity to expedite inspections.
